Description
Brand - MRC
Item Number - 316S H503 C3 MRC
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 80
Outer (D) MM - 170
Width (B) MM - 39
Weight (kg) - 3.69
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
