Description
Brand - Link-Belt
Item Number - 2K1495Z Link-Belt
Category - Pillow Blocks Sleeve Bearing
UPC - 662327188030
Material - 10438869
Model - 2K1400Z
Bore Size (in) - 5.9375 in
Housing Coating - POWDER COATED
Housing Material - Cast Steel
Housing Style - Pillow Block
Housing Type - Pillow Block, Four Bolt, Gibbed Joint
Base to Centerline Height (in) - 5.5 in
Bearing Brand - LINK-BELT RIGID SLEEVE
Bearing Type - BRONZE SLEEVE BRG
Distance Between Bolt Holes (in) - 16.5 in
Grease Fitting Size - 1/2 NPT
Height - 9.75
Insert - 285BY331
Length - 20.25
Lubrication Type - NOT GREASED FROM FACTORY
Weight (kg) - 97.52228
Shims - 131Y36621 QTY 12
Unit of Dimension - IN
Volume - 0.275
Volume Unit - Hectoliter
Width - 8.5
