Description
Brand - Link-Belt
Item Number - 2K1480Z Link-Belt
Category - Pillow Blocks Sleeve Bearing
UPC - 662327434762
Material - 10431038
Model - 2K1400Z
Bore Size (in) - 5 in
Housing Coating - POWDER COATED
Housing Material - Cast Steel
Housing Style - Pillow Block
Housing Type - Pillow Block, Four Bolt, Gibbed Joint
Base to Centerline Height (in) - 4.5 in
Bearing Brand - LINK-BELT RIGID SLEEVE
Bearing Type - BRONZE SLEEVE BRG
Distance Between Bolt Holes (in) - 15 in
Grease Fitting Size - 1/2 NPT
Insert - 285Y22232
Lubrication Type - NOT GREASED FROM FACTORY
Weight (kg) - 58.18224584
Shims - 131Y36617 QTY 8
