Description
Brand - CPM
Part Number - 2774 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 220 mm
Outer Diameter (D) - 310 mm
Width (B) - 24 mm
Dimension (b) - 24 mm
Dimension (P) - 24 mm
Dimension (Dp. 1) - 285 mm
Dimension (n° × d1) - 6xM12
Angle (α) - 35°
Basic Dynamic Load Rating (Cr) - 111 kN
Basic Static Load Rating (Cor) - 244 kN
♦♦ Images are for representation purposes only
