2574 CPM

Brand - CPM
Part Number - 2574 CPM
Category - Slewing Bearing

Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 140 mm
Outer Diameter (D) - 300 mm
Width (B) - 30 mm
Dimension (b) - 30 mm
Dimension (P) - 36 mm
Dimension (Dp. 1) - 270 mm
Dimension (Dp. 2) - 170 mm
Dimension (n° × d1) - 12xM16
Dimension (n° × d2) - 12x18
Angle (α) - 35°
Basic Dynamic Load Rating (Cr) - 106.9 kN
Basic Static Load Rating (Cor) - 213.4 kN

♦♦ Images are for representation purposes only
