Description
Brand - CPM
Part Number - 2569 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 240 mm
Outer Diameter (D) - 440 mm
Width (B) - 53 mm
Dimension (b) - 53 mm
Dimension (P) - 60 mm
Dimension (Dp. 1) - 400 mm
Dimension (Dp. 2) - 280 mm
Dimension (n° × d1) - 16xM12
Dimension (n° × d2) - 16x13.5
Angle (α) - 50°
Basic Dynamic Load Rating (Ca) - 350 kN
Basic Static Load Rating (Coa) - 1681 kN
♦♦ Images are for representation purposes only
