Description
Brand - CPM
Part Number - 2568 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 130 mm
Outer Diameter (D) - 205 mm
Width (B) - 24.8 mm
Dimension (b) - 24.8 mm
Dimension (P) - 25.4 mm
Dimension (Dp. 1) - 190 mm
Dimension (Dp. 2) - 145 mm
Dimension (n° × d1) - 12x6.8
Dimension (n° × d2) - 12x6.8
Angle (α) - 50°
Basic Dynamic Load Rating (Ca) - 79 kN
Basic Static Load Rating (Coa) - 335 kN
♦♦ Images are for representation purposes only
Part Number - 2568 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 130 mm
Outer Diameter (D) - 205 mm
Width (B) - 24.8 mm
Dimension (b) - 24.8 mm
Dimension (P) - 25.4 mm
Dimension (Dp. 1) - 190 mm
Dimension (Dp. 2) - 145 mm
Dimension (n° × d1) - 12x6.8
Dimension (n° × d2) - 12x6.8
Angle (α) - 50°
Basic Dynamic Load Rating (Ca) - 79 kN
Basic Static Load Rating (Coa) - 335 kN
♦♦ Images are for representation purposes only
