Description
Brand - CPM
Part Number - 2549 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 260 mm
Outer Diameter (D) - 430 mm
Width (B) - 66 mm
Dimension (b) - 62 mm
Dimension (P) - 77 mm
Dimension (Dp. 1) - 400 mm
Dimension (Dp. 2) - 290 mm
Dimension (n° × d1) - 24x15
Dimension (n° × d2) - 20x16
Angle (α) - 40°
Basic Dynamic Load Rating (Cr) - 382 kN
Basic Static Load Rating (Cor) - 795 kN
♦♦ Images are for representation purposes only
Part Number - 2549 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 260 mm
Outer Diameter (D) - 430 mm
Width (B) - 66 mm
Dimension (b) - 62 mm
Dimension (P) - 77 mm
Dimension (Dp. 1) - 400 mm
Dimension (Dp. 2) - 290 mm
Dimension (n° × d1) - 24x15
Dimension (n° × d2) - 20x16
Angle (α) - 40°
Basic Dynamic Load Rating (Cr) - 382 kN
Basic Static Load Rating (Cor) - 795 kN
♦♦ Images are for representation purposes only
