Description
Brand - CPM
Part Number - 2547 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 192 mm
Outer Diameter (D) - 330 mm
Width (B) - 52 mm
Dimension (b) - 53 mm
Dimension (P) - 53 mm
Dimension (Dp. 1) - 305 mm
Dimension (Dp. 2) - 215 mm
Dimension (n° × d1) - 16xM12
Dimension (n° × d2) - 17xM12, 15x13
Angle (α) - 30°
Basic Dynamic Load Rating (Cr) - 270 kN
Basic Static Load Rating (Cor) - 460 kN
♦♦ Images are for representation purposes only
Part Number - 2547 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 192 mm
Outer Diameter (D) - 330 mm
Width (B) - 52 mm
Dimension (b) - 53 mm
Dimension (P) - 53 mm
Dimension (Dp. 1) - 305 mm
Dimension (Dp. 2) - 215 mm
Dimension (n° × d1) - 16xM12
Dimension (n° × d2) - 17xM12, 15x13
Angle (α) - 30°
Basic Dynamic Load Rating (Cr) - 270 kN
Basic Static Load Rating (Cor) - 460 kN
♦♦ Images are for representation purposes only
