Description
Brand - CPM
Part Number - 2477 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 82 mm
Outer Diameter (D) - 260 mm
Width (B) - 23.5 mm
Dimension (b) - 21.7 mm
Dimension (P) - 25 mm
Dimension (Dp. 1) - 240 mm
Dimension (Dp. 2) - Available on Request
Dimension (n° × d1) - 6xM10
Dimension (n° × d2) - Available on Request
Angle (α) - 35°
Basic Dynamic Load Rating (Cr) - 14.9 kN
Basic Static Load Rating (Cor) - 24.9 kN
♦♦ Images are for representation purposes only
Part Number - 2477 CPM
Category - Slewing Bearing
Principal Dimensions & Load Ratings (Metric):
Inner Diameter (d) - 82 mm
Outer Diameter (D) - 260 mm
Width (B) - 23.5 mm
Dimension (b) - 21.7 mm
Dimension (P) - 25 mm
Dimension (Dp. 1) - 240 mm
Dimension (Dp. 2) - Available on Request
Dimension (n° × d1) - 6xM10
Dimension (n° × d2) - Available on Request
Angle (α) - 35°
Basic Dynamic Load Rating (Cr) - 14.9 kN
Basic Static Load Rating (Cor) - 24.9 kN
♦♦ Images are for representation purposes only
