24136-BE-XL-2VSR FAG

Brand - FAG
Item Number - 24136-BE-XL-2VSR FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 33.2
Inner Diameter (d) mm - 180
Outer Diameter (D) mm - 300
Width (B) mm - 118
Minimum Chamfer Dimension (r) mm - 3
Outer Ring Bore Diameter (D1) mm - 276.3
Inner Ring Raceway Diameter (d2) mm - 196.2
Lubrication Hole Diameter (ds) mm - 6.3
Lubrication Groove Width (ns) mm - 12.2
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 194
Maximum Housing Connection Diameter (Da) mm - 286
Maximum Undercut Radius (ra) mm - 2.5
Basic dynamic Radial Load Rating (Cr) N - 1460000
Basic Static Radial Load Rating (C0r) N - 2170000
Calculation Factor (e) - 0.36
Calculation Factor (Y1) - 1.86
Calculation Factor (Y2) - 2.77
Calculation Factor (Y0) - 1.82
Radial Fatigue Load Limit (Cur) N - 208000
Limiting Speed (nG) 1/min - 500

Suffixes:
BE - Floating Rib Washer on Inner Ring
XL - X-Life
2VSR - Steel-Reinforced Lip Seal on Both Sides Made From Fluoro Rubber (FKM), Grease Filling Level 55% to 65%, Filled With High-Temperature Grease
