24040-BE-XL-2VSR FAG

Brand - FAG
Item Number - 24040-BE-XL-2VSR FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 30.1
Inner Diameter (d) mm - 200
Outer Diameter (D) mm - 310
Width (B) mm - 109
Minimum Chamfer Dimension (r) mm - 2.1
Outer Ring Bore Diameter (D1) mm - 287.8
Inner Ring Raceway Diameter (d2) mm - 217
Lubrication Hole Diameter (ds) mm - 6.3
Lubrication Groove Width (ns) mm - 12.2
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 210.2
Maximum Housing Connection Diameter (Da) mm - 299.8
Maximum Undercut Radius (ra) mm - 2.1
Basic dynamic Radial Load Rating (Cr) N - 1350000
Basic Static Radial Load Rating (C0r) N - 2150000
Calculation Factor (e) - 0.32
Calculation Factor (Y1) - 2.13
Calculation Factor (Y2) - 3.17
Calculation Factor (Y0) - 2.08
Radial Fatigue Load Limit (Cur) N - 221000
Limiting Speed (nG) 1/min - 500

Suffixes:
BE - Floating Rib Washer on Inner Ring
XL - X-Life
2VSR - Steel-Reinforced Lip Seal on Both Sides Made From Fluoro Rubber (FKM), Grease Filling Level 55% to 65%, Filled With High-Temperature Grease
