24036-BE-XL-2VSR FAG

Brand - FAG
Item Number - 24036-BE-XL-2VSR FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 22.7
Inner Diameter (d) mm - 180
Outer Diameter (D) mm - 280
Width (B) mm - 100
Minimum Chamfer Dimension (r) mm - 2.1
Outer Ring Bore Diameter (D1) mm - 259.6
Inner Ring Raceway Diameter (d2) mm - 195.6
Lubrication Hole Diameter (ds) mm - 4.8
Lubrication Groove Width (ns) mm - 9.5
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 190.2
Maximum Housing Connection Diameter (Da) mm - 269.8
Maximum Undercut Radius (ra) mm - 2.1
Basic dynamic Radial Load Rating (Cr) N - 1130000
Basic Static Radial Load Rating (C0r) N - 1770000
Calculation Factor (e) - 0.32
Calculation Factor (Y1) - 2.1
Calculation Factor (Y2) - 3.13
Calculation Factor (Y0) - 2.06
Radial Fatigue Load Limit (Cur) N - 185000
Limiting Speed (nG) 1/min - 550

Suffixes:
BE - Floating Rib Washer on Inner Ring
XL - X-Life
2VSR - Steel-Reinforced Lip Seal on Both Sides Made From Fluoro Rubber (FKM), Grease Filling Level 55% to 65%, Filled With High-Temperature Grease

** Images are for representation purposes only
