Description
Brand - TIMKEN
Item Number - 23256CAKW33 TIMKEN
Category - Spherical Roller Bearing
Inner (d) MM - 280
Outer (D) MM - 500
Width (B) MM - 176
Inner (d) Inch - 11.0236
Outer (D) Inch - 19.685
Width (B) Inch - 6.9291
Weight (kg) - 144
Bore - K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement - W33 - Lubrication Groove and 3 Holes
Seal - No Seal
Cage Type - M - Brass Cage
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution - Non Vibrating Screen Execution
CA - One-Piece Machined Brass Cage, Double-Pronged, Retaining Flanges On The Inner Ring And Guide Ring Centered On The Inner Ring
K - Tapered Bore, Taper 1:12
