Description
Brand - TIMKEN
Item Number - 23248YMBW507C08C3 TIMKEN
Also known as - 23248EMW507C08C3
Category - Spherical Roller Bearing
Inner (d) MM - 240
Outer (D) MM - 440
Width (B) MM - 160
Inner (d) Inch - 9.4488
Outer (D) Inch - 17.3228
Width (B) Inch - 6.2992
Weight (kg) - 109
Bore - C - Cylindrical Bore
Lubrication Enhancement - W57 - W4 + W31 + W33 Combined
Seal - No Seal
Cage Type - M - Brass Cage
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Higher Running Acc. ISO Cl.5
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution - Non Vibrating Screen Execution
YMB - One Piece Brass, Finger Type, Land Piloted
W507 - Combination Of W4 (Mark High And Low Points Of Eccentricity On Face Of Rings) And W31 (Bearing Inspected To Certain Quality Control Requirements) And W33 (Lubrication Groove And Three Holes In Bearing Outer Ring)
