22236LBKC3 Link-Belt

Brand - Link-Belt
Part Number - 22236LBKC3 Link-Belt
Category - Bearing Inserts (Unmounted Replacements) Spherical Roller Bearings
UPC - 782935473882
Material - 10979748
Model - 22200LBK
Bore Size (in) - 7.0866 in
Bore Size (mm) - 180 mm
Locking Type - Tapered Bore
Bearing Brand - LINK-BELT SPHER SPLIT BLKS TU
Bearing Type - SPHERICAL ROLLER BRG
Bore Type - Tapered
C Dynamic Load Rating - 255000 lb
Co Static Load Rating - 365000 lb
Height - 5.38
Housing Fillet Radius (in) - 0.12 in
Length - 10.88
Maximum Shoulder Diameter (in) - 11.90 in
Maximum Speed (RPM) - 1300 GREASE - 1500 OIL rpm
Maximum Speed Using Grease (RPM) - 1300 rpm
Maximum Speed Using Oil (RPM) - 1500 rpm
Minimum Shoulder Diameter (in) - 7.80 in
Mounted Clearance - C3 GREATER THAN C0 NORMAL
Weight (kg) - 66.3
Outside Diameter (in) - 12.5984 in
Retainer Type - BRASS
Sealed - None
Size Code - 22236
