Description
Brand - FAG
Item Number - 22232-E1A-XL-2RSR-M FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 23.3
Inner Diameter (d) mm - 160
Outer Diameter (D) mm - 290
Width (B) mm - 80
Minimum Chamfer Dimension (r) mm - 3
Lubrication Hole Diameter (ds) mm - 8
Lubrication Groove Width (ns) mm - 15
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 174
Maximum Housing Connection Diameter (Da) mm - 276
Maximum Undercut Radius (ra) mm - 2.5
Basic dynamic Radial Load Rating (Cr) N - 1080000
Basic Static Radial Load Rating (C0r) N - 1300000
Calculation Factor (e) - 0.24
Calculation Factor (Y1) - 2.79
Calculation Factor (Y2) - 4.15
Calculation Factor (Y0) - 2.73
Radial Fatigue Load Limit (Cur) N - 128000
Limiting Speed (nG) 1/min - 700
Suffixes:
E1 - Without Central Rib on Inner Ring
XL - X-Life
2RSR - Steel-Reinforced Lip Seal on Both Sides Made From Nitrile Rubber (NBR), Grease Filling Level 25% to 40%, Filled with High-Pressure Grease
M - Single-Piece Solid Brass Cage, Guided by the Rolling Elements
** Images are for representation purposes only
