Description
Brand - FAG
Item Number - 22228-E1A-XL-2RSR-M FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 14.1
Inner Diameter (d) mm - 140
Outer Diameter (D) mm - 250
Width (B) mm - 68
Minimum Chamfer Dimension (r) mm - 3
Lubrication Hole Diameter (ds) mm - 6.3
Lubrication Groove Width (ns) mm - 12.2
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 154
Maximum Housing Connection Diameter (Da) mm - 236
Maximum Undercut Radius (ra) mm - 2.5
Basic dynamic Radial Load Rating (Cr) N - 830000
Basic Static Radial Load Rating (C0r) N - 970000
Calculation Factor (e) - 0.24
Calculation Factor (Y1) - 2.81
Calculation Factor (Y2) - 4.19
Calculation Factor (Y0) - 2.75
Radial Fatigue Load Limit (Cur) N - 100000
Limiting Speed (nG) 1/min - 820
Suffixes:
E1 - Without Central Rib on Inner Ring
XL - X-Life
2RSR - Steel-Reinforced Lip Seal on Both Sides Made From Nitrile Rubber (NBR), Grease Filling Level 25% to 40%, Filled with High-Pressure Grease
M - Single-Piece Solid Brass Cage, Guided by the Rolling Elements
** Images are for representation purposes only
