Description
Brand - FAG
Item Number - 2208-TVH-C3>J FAG
Category - Self Aligning Ball Bearing Double Row
Also known as - 2208ETN9/C3 2208TNGC3 2208-TVH-C3 3002417630030
Inner (d) MM - 40
Outer (D) MM - 80
Width (B) MM - 23
Inner (d) Inch - 1.5748
Outer (D) Inch - 3.1496
Width (B) Inch - 0.9055
Weight (kg) - 0.505
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - P - Plastic Molded Cage
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
