21587 Link-Belt

Brand - Link-Belt
Item Number - 21587 Link-Belt
Category - Pillow Blocks Sleeve Bearing
UPC - 662327194093
Material - 10420589
Model - 21500
Bore Size (in) - 5.4375 in
Housing Coating - POWDER COATED
Housing Material - Cast Iron
Housing Style - Pillow Block
Housing Type - Pillow Block, Four Bolt, Split 40 degree
Sleeve Material - Babbitt
Base to Centerline Height (in) - 5 in
Bearing Brand - LINK-BELT RIGID SLEEVE
Bearing Type - BABBITT SLEEVE BRG
Bolt Hole Spacing Width (in) - 4 1/2 in
Bore Length (in) - 11 in
Distance Between Bolt Holes (in) - 15 3/4 in
Expansion Type - Non-Expansion Bearing (Fixed)
Grease Fitting Size - 1/2 NPT
Lubrication Type - NOT GREASED FROM FACTORY
Maximum Temperature (C) - 54 C
Maximum Temperature (F) - 130 F
Mounting Bolt Hole Slot Length (in) - 1 7/8 in
Mounting Bolt Size (in) - 1 in
Mounting Pad Height (in) - 2 in
Mounting Pad Length (in) - 19 3/4 in
Mounting Pad Width (in) - 8 in
Weight (kg) - 67.585208
Pipe Tap Size (in) - 1/2 in
Required Distance for Cap Removal (in) - 13 1/2 in
