Description
Brand - FAG
Item Number - 203-KXN4 FAG
EAN - 4012802414943
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 17
Outer (D) MM - 40
Width (B) MM - 13
Weight (kg) - 0.07
Bore - C - Cylindrical Bore
Seal - RS - Rubber Seal on One Side
Cage Type - P - Plastic Molded Cage
External Modification - N - Snap Ring Groove in Outer Ring
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
