136961 DODGE - FB-SCEZ-20M-SHCR


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 136961 DODGE - FB-SCEZ-20M-SHCR
Category - E-Z Kleen Mounted Bearings (SCEZ SHCR Normal Duty Stainless Steel Flange Bracket Bearings)
Series - 204
Shaft Size (mm) - 20
Description - FB-SCEZ-20M-SHCR
Weight (kg) - 0.45
Length Through Bore (A) mm - 31.2
Overall Length (B) mm - 106.4
Thickness (C) mm - 31.8
Bolt Center to Center Length (D) mm - 38.1
E (mm) - 42.9
F-Bolt Diameter - M10
G (mm) - 22.4
H (mm) - 7.9
I (mm) - 76.2
Overall Width (J) mm - 60.5
K (mm) - 22.9
L (mm) - 28.4
M (mm) - 60.5
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
FB - Flanged bracket
SC - Wide inner ring, normal duty, 65° setscrew locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert

** Images are for representation purposes only
