129366 DODGE - F2B-GTEZ-40M-SHCR


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 129366 DODGE - F2B-GTEZ-40M-SHCR
Category - E-Z KLEEN Mounted Bearings (Complete Unit of GTEZ Normal Duty Stainless Steel 2-Bolt Flange Bearings)
Series - 208
Shaft Size (mm) - 40
Description - F2B-GTEZ-40M-SHCR
Part Number (Unit Without Adapter) - 129577
Description (Unit Without Adapter) - F2B-GTEZ-08-SHCR
Part Number (Adapter & Nut Assembly) - 129984
Description (Adapter & Nut Assembly) - AN-GT-08-40M-CR
Weight (kg) - 1.77
Length Through Bore (A) mm - 46.7
Overall Length (B) mm - 170.4
Thickness (C) inch - 51.1
Bolt Center to Center Length (D) mm - 143.5
F-Bolt Diameter - M12
H (mm) - 10.7
J (mm) - 17
L (mm) - 66.5
Overall Width (M) mm - 97.5
Z (mm) - 51.3
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
F2B - 2-bolt flange
GT - Wide inner ring, normal duty, thin wall adapter locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert

** Images are for representation purposes only
