127867 DODGE - INS-SC-50M-SS


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 127867 DODGE - INS-SC-50M-SS
Category - Ultra Kleen Mounted Bearings (SC Normal Duty Bearing Stainless Steel Inserts for Ultra Kleen Bearings)
Series - 210
Shaft Size (mm) - 50
Description - INS-SC-50M-SS
Weight (kg) - 0.67
Overall Width (A) mm - 49.3
C (mm) - 22
Overall Outer Diameter (D) mm - 90
J (mm) - 6.4
L (mm) - 61.7
N (mm) - M10x1.5
W (mm) - 19.1
Y (mm) - 30.2
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
INS - Insert
SC - Wide inner ring, normal duty, 65° setscrew locking
M - Metric
SS - Stainless Steel Insert

** Images are for representation purposes only
