Description
Brand - DODGE
Item Number - 127826 DODGE - INS-SC-115-SS
Category - Ultra Kleen Mounted Bearings (SC Normal Duty Bearing Stainless Steel Inserts for Ultra Kleen Bearings)
Series - 210
Shaft Size (inch) - 1.9375
Description - INS-SC-115-SS
Weight (lbs) - 1.48
Overall Width (A) inch - 1.94
C (inch) - 0.87
Overall Outer Diameter (D) inch - 3.5433
J (inch) - 0.25
L (inch) - 2.43
N (inch) - 0.375-24
W (inch) - 0.75
Y (inch) - 1.19
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
INS - Insert
SC - Wide inner ring, normal duty, 65° setscrew locking
SS - Stainless Steel Insert
** Images are for representation purposes only
