Description
Brand - DODGE
Item Number - 127818 DODGE - INS-SC-012-SS
Category - Ultra Kleen Mounted Bearings (SC Normal Duty Bearing Stainless Steel Inserts for Ultra Kleen Bearings)
Series - 204
Shaft Size (inch) - 0.75
Description - INS-SC-012-SS
Weight (lbs) - 0.32
Overall Width (A) inch - 1.23
C (inch) - 0.58
Overall Outer Diameter (D) inch - 1.8504
J (inch) - 0.15
L (inch) - 1.11
N (inch) - 0.25-28
W (inch) - 0.5
Y (inch) - 0.73
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
INS - Insert
SC - Wide inner ring, normal duty, 65° setscrew locking
SS - Stainless Steel Insert
** Images are for representation purposes only
