127708 DODGE - F2B-SCEZ-50M-SHCR


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 127708 DODGE - F2B-SCEZ-50M-SHCR
Category - E-Z KLEEN Mounted Bearings (SCEZ Normal Duty Stainless Steel 2-Bolt Flange Bearings)
Shaft Size (mm) - 50
Description - F2B-SCEZ-50M-SHCR
Description (With Corrosion Resistant Insert) - F2B-SCEZ-50M-SH
Weight (kg) - 1.87
Length Through Bore (A) mm - 49.3
Overall Length (B) mm - 190
Thickness (C) mm - 50.3
Bolt Center to Center Length (D) mm - 157
F-Bolt Diameter - M16
H (mm) - 12.2
J (mm) - 16
L (mm) - 61.7
Overall Width (M) mm - 109.5
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
F2B - 2-bolt flange
SC - Wide inner ring, normal duty, 65° setscrew locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert

** Images are for representation purposes only
