127701 DODGE - P2B-SCBEZ-40M-SHCR


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 127701 DODGE - P2B-SCBEZ-40M-SHCR
Category - E-Z KLEEN Mounted Bearings With Corrosion Resistant Insert (SCEZ Normal Duty Stainless Steel Housed Pillow Blocks)
Series - 208 (SCB)
Shaft Size (mm) - 40
Description - P2B-SCBEZ-40M-SHCR
Description (Standard Insert with Flingers) - P2B-SCBEZ-40M-SH
Weight (kg) - 1.74
Length Through Bore (A) mm - 49.3
Overall Length (B) mm - 177.8
Width (C) mm - 38.1
Bolt to Bolt Minimum Distance (D min) mm - 131.6
Bolt to Bolt Maximum Distance (D max) mm - 152.4
F-Bolt Diameter - M12
G (mm) - 24.6
H (mm) - 14.2
Overall Height (J) mm - 96.8
L (mm) - 52.1
Base to Center Height (M) mm - 49.2
R (mm) - 19.1
S (mm) - 30.2
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow block, 2 bolt base
SC - Wide inner ring, normal duty, 65° setscrew locking
BEZ - Low backing height pillow block, E-Z KLEEN/ULTRA KLEEN
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert

** Images are for representation purposes only
