127697 DODGE - P2B-SCEZ-20M-SHCR


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 127697 DODGE - P2B-SCEZ-20M-SHCR
Category - E-Z KLEEN Mounted Bearings With Corrosion Resistant Insert (SCEZ Normal Duty Stainless Steel Housed Pillow Blocks)
Series - 204
Shaft Size (mm) - 20
Description - P2B-SCEZ-20M-SHCR
Description (Standard Insert with Flingers) - P2B-SCEZ-20M-SH
Weight (kg) - 0.59
Length Through Bore (A) mm - 31.2
Overall Length (B) mm - 127
Width (C) mm - 25.4
Bolt to Bolt Minimum Distance (D min) mm - 85.9
Bolt to Bolt Maximum Distance (D max) mm - 106.2
F-Bolt Diameter - M10
G (mm) - 21.3
H (mm) - 12.7
Overall Height (J) mm - 63.5
L (mm) - 28.4
Base to Center Height (M) mm - 33.3
R (mm) - 12.7
S (mm) - 18.5
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow block, 2 bolt base
SC - Wide inner ring, normal duty, 65° setscrew locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert

** Images are for representation purposes only
