127623 DODGE - P2B-DLEZ-20M-PCR

Brand - DODGE
Item Number - 127623 DODGE - P2B-DLEZ-20M-PCR
Category - E-Z KLEEN Mounted Bearings (DLEZ Normal Duty Polymer Housed Pillow Blocks)
Series - 204
Shaft Size (mm) - 20
Description - P2B-DLEZ-20M-PCR
Description (Standard Insert With Flingers) - P2B-DLEZ-20M-P
Weight (kg) - 0.42
Length Through Bore (A) mm - 32.5
Overall Length (B) mm - 127.5
Width (C) mm - 37.6
Bolt to Bolt Minimum Distance (D min) mm - 93
Bolt to Bolt Maximum Distance (D max) mm - 99.6
F-Bolt Diameter - M10
G (mm) - 15
H (mm) - 15.5
Overall Height (J) mm - 66.8
L (mm) - 43.4
Base to Center Height (M) mm - 33.4
R (mm) - 12.7
S (mm) - 19.8
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow block, 2 bolt base
DL - Wide inner ring, normal duty, concentric clamp collar
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
P - Polymer housing
CR - Corrosion resistant insert

** Images are for representation purposes only
