127578 DODGE - P2B-DLEZ-012-PCR

Brand - DODGE
Item Number - 127578 DODGE - P2B-DLEZ-012-PCR
Category - E-Z KLEEN Mounted Bearings (DLEZ Normal Duty Polymer Housed Pillow Blocks)
Series - 204
Shaft Size (inch) - 0.75
Description - P2B-DLEZ-012-PCR
Description (Standard Insert With Flingers) - P2B-DLEZ-012-P
Weight (lbs) - 0.92
Length Through Bore (A) inch - 1.28
Overall Length (B) inch - 5.02
Width (C) inch - 1.48
Bolt to Bolt Minimum Distance (D min) inch - 3.66
Bolt to Bolt Maximum Distance (D max) inch - 3.92
F-Bolt Diameter (inch) - 0.375
G (inch) - 0.59
H (inch) - 0.61
Overall Height (J) inch - 2.63
L (inch) - 1.71
Base to Center Height (M) inch - 1.31
R (inch) - 0.5
S (inch) - 0.78
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow block, 2 bolt base
DL - Wide inner ring, normal duty, concentric clamp collar
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
P - Polymer housing
CR - Corrosion resistant insert

** Images are for representation purposes only
