127577 DODGE - WSTU-SCEZ-35M-PCR

Brand - DODGE
Item Number - 127577 DODGE - WSTU-SCEZ-35M-PCR
Category - E-Z KLEEN Mounted Bearings (SCEZ Normal Duty Polymer Housed Wide Slot Take-Up Bearings)
Series - 207
Shaft Size (mm) - 35
Description - WSTU-SCEZ-35M-PCR
Description (Standard Insert With Flingers) - WSTU-SCEZ-35M-P
Weight (kg) - 0.69
Take-up Frame Number - WS308
Length Through Bore (A) mm - 43.4
Overall Length (B) mm - 126.7
C (mm) - 13.84/13.08
D (mm) - 57.2
E (mm) - 78.7
F (Thread Shaft) mm - 19.1
G (mm) - 14.2
H (mm) - 16.5
J (mm) - 61.2
K (mm) - 20.6
L (mm) - 46.7
M (mm) - 89.93/89.15
Overall Width (N) mm - 106.7
R (mm) - 17
S (mm) - 26.4
Thickness (T) mm - 41.1
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
WSTU - Wide slot take-up
SC - Wide inner ring, normal duty, 65° setscrew locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
M - Metric
P - Polymer housing
CR - Corrosion resistant insert

** Images are for representation purposes only
