125517 DODGE - F2B-VSC-010


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - DODGE
Item Number - 125517 DODGE - F2B-VSC-010
Category - Setscrew VSC Ball Bearings (VSC Intermediate Duty 2-Bolt Flange Bearings)
Series - 203
Shaft Size (inch) - 0.625
Description - F2B-VSC-010
Description (No-Lube/Sealed for Life) - F2B-VSC-010-NL
Weight (lbs) - 0.7
Length Through Bore (A) inch - 1
Overall Length (B) inch - 3.88
Thickness (C) inch - 1.17
Bolt Center to Center Length (D) inch - 3
F-Bolt Diameter (inch) - 0.375
H (inch) - 0.38
J (inch) - 0.32
L (inch) - 0.96
Overall Width (M) inch - 2.13
N (inch) - 1.13
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
F2B - 2 bolt flange

** Images are for representation purposes only
