Description
Brand - ZEN
Item Number - 11205 ZEN
Category - Steel Inserts (11200)
Inner Diameter (d) mm - 25
D2 (mm) - 52
Bi (mm) - 44
Width (B) mm - 15
D1 (mm) - 43.6
d1 (mm) - 33.3
r (mm) - 1
Dynamic Load Rating (N) - 11685
Static Load Rating (N) - 3100
Limiting Speed - 14725
Weight (kg) - 0.220
Radial Play - 0.005-0.020
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
Cage Material - 08F
** Images are for representation purposes only
