Description
Brand - DODGE
Item Number - 076277 DODGE - WSTU-SCED-35M
Category - Extreme Duty Setscrew Ball Bearings (SCED Normal Duty Wide Solt Take-Up Bearings)
Series - 207
Shaft Size (mm) - 35
Description - WSTU-SCED-35M
Weight (kg) - 1.6
Take-Up Frame Size - WS308
Length Through Bore (A) mm - 43.4
Overall Length (B) mm - 123.7
Thickness (C) mm - 13.49
D (mm) - 63.5
E (mm) - 77.7
F (Screw Diameter) mm - 19.1
G (mm) - 12.7
H (mm) - 16
J (mm) - 63.5
K (mm) - 36.6
L (mm) - 46.7
M (mm) - 88.39/89.15
Overall Width (N) mm - 104.9
R (mm) - 17
S (mm) - 26.4
T (mm) - 41.3
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
WSTU - Wide slot take-up
SCED - Extreme duty
M - Metric
** Images are for representation purposes only
