Description
Brand - DODGE
Item Number - 073007 DODGE - P2B-GTEZ-200-SHCR
Category - E-Z Kleen Mounted Bearings (Complete Unit of GTEZ Normal Duty Stainless Steel Housed Pillow Blocks)
Series - 210
Description - P2B-GTEZ-200-SHCR
Shaft Size (inch) - 2.0
Weight (lbs) - 6.14
Length Through Bore (A) inch - 1.86
Overall Length (B) inch - 8
Width (C) inch - 1.63
Bolt to Bolt Minimum Distance (D min) inch - 5.76
Bolt to Bolt Maximum Distance (D max) inch - 6.68
F-Bolt Diameter (inch) - 0.625
G (inch) - 1.14
H (inch) - 0.62
Overall Height (J) inch - 4.31
L (inch) - 3.13
Base to Center Height (M) inch - 2.25
R* (inch) - 0.63
S* (inch) - 1.23
Z (inch) - 1.26
Part Number (Unit Without Adapter) - 129564
Description (Unit Without Adapter) - P2B-GTEZ-10-SHCR
Part Number (Adapter & Nut Assembly) - 129979
Description (Adapter & Nut Assembly) - AN-GT-10-200-CR
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
P2B - Pillow block, 2 bolt base
GT - Wide inner ring, normal duty, thin wall adapter locking
EZ - E-Z KLEEN/ULTRA KLEEN (used with polymer or stainless steel housed units)
SH - Stainless Steel Housing
CR - Corrosion resistant insert
* dimensions will vary slightly depending on true shaft diameter
** Images are for representation purposes only
