071184 DODGE - EP2B-IP-107LE

Brand - DODGE
Item Number - 071184 DODGE - EP2B-IP-107LE
Category - IMPERIAL - IP Pillow Block 2-Bolt with Type E Dimensions (Labyrinth Seal - Expansion)
Type - Push-Pull Adapter
Bearing - 22208
Shaft Size (inch) - 1.4375
Part Name - EP2B-IP-107LE
Length Through Bore (A) inch - 2.63
Overall Length (B) inch - 7.37
Width (C) inch - 2.12
Bolt to Bolt Minimum Distance (D min) inch - 5.63
Bolt to Bolt Maximum Distance (D max) inch - 5.88
F-Bolt Diameter (inch) - 0.5
G (inch) - 0.75
H (inch) - 1.13
Overall Height (J) inch - 3.85
L (inch) - 2.72
Base to Center Height (M) inch - 1.875
S (inch) - 1.59
Total Expansion (X) inch - 0.15625
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
E - prefix denotes Type E dimensioned housing
P2B - Pillow Block 2 Bolt Base
IP - IMPERIAL
L - Labyrinth Metallic Seal
E - Expansion Type Bearing

** Images are for representation purposes only
