071102 DODGE - P2B530-ISN-135MFR

Brand - DODGE
Item Number - 071102 DODGE - P2B530-ISN-135MFR
Category - IMPERIAL - ISN Metric Pillow Block 2-Bolt with Trident Seal (Non-Expansion)
Type - Push-Pull Adapter
Bearing - 22228
Shaft Size (mm) - 135
Description - P2B530-ISN-135MFR
Length Through Bore (A) mm - 156.8
Overall Length (B) mm - 539.8
Width (C) mm - 159.8
Bolt to Bolt Minimum Distance (D min) mm - 443
Bolt to Bolt Maximum Distance (D max) mm - 457
F-Bolt Diameter - M30
G (mm) - 42
H (mm) - 60
Overall Height (J) mm - 312.5
L (mm) - 222.2
Base to Center Height (M) mm - 160
R (mm) - 51.8
S (mm) - 105
T (mm) - 16.3
Y (mm) - 1.02
Z (mm) - 150.4
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow Block 2 Bolt Base
5XX - for interchangeable SAF style housings
ISN - Imperial SN
M - Metric
F - Non-expansion
R - Trident rubbing seal

** Images are for representation purposes only
