Description
Brand - DODGE
Item Number - 071023 DODGE - P2B513-ISN-060MLR
Category - IMPERIAL - ISN Metric Pillow Block 2-Bolt with Trident Seal (Expansion)
Type - Push-Pull Adapter
Bearing - 22213
Shaft Size (mm) - 60
Description - P2B513-ISN-060MLR
Length Through Bore (A) mm - 86.9
Overall Length (B) mm - 274.9
Width (C) mm - 80.2
Bolt to Bolt Minimum Distance (D min) mm - 205
Bolt to Bolt Maximum Distance (D max) mm - 235
F-Bolt Diameter - M16
G (mm) - 33
H (mm) - 30
Overall Height (J) mm - 152.4
L (mm) - 96.5
Base to Center Height (M) mm - 80
S (mm) - 59.7
T (mm) - 7
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
P2B - Pillow Block 2 Bolt Base
5XX - for interchangeable SAF style housings
ISN - Imperial SN
M - Metric
L - Expansion
R - Trident rubbing seal
** Images are for representation purposes only
