071001 DODGE - P2B508-ISN-035MFR

Brand - DODGE
Item Number - 071001 DODGE - P2B508-ISN-035MFR
Category - IMPERIAL - ISN Metric Pillow Block 2-Bolt with Trident Seal (Non-Expansion)
Type - Push-Pull Adapter
Bearing - 22208
Shaft Size (mm) - 35
Description - P2B508-ISN-035MFR
Length Through Bore (A) mm - 66.7
Overall Length (B) mm - 205.9
Width (C) mm - 60.2
Bolt to Bolt Minimum Distance (D min) mm - 150
Bolt to Bolt Maximum Distance (D max) mm - 174.6
F-Bolt Diameter - M12
G (mm) - 27.3
H (mm) - 25
Overall Height (J) mm - 110.8
L (mm) - 67.6
Base to Center Height (M) mm - 60
R (mm) - 22.6
S (mm) - 44.1
T (mm) - 4
Y (mm) - 0.51
Z (mm) - 45.7
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request

Notes :
P2B - Pillow Block 2 Bolt Base
5XX - for interchangeable SAF style housings
ISN - Imperial SN
M - Metric
F - Non-expansion
R - Trident rubbing seal

** Images are for representation purposes only
