039577 DODGE - CP2B511-USAF-115TT

Brand - DODGE
Item Number - 039577 DODGE - CP2B511-USAF-115TT
Category - USAF 500 Adapter Mount Pillow Block with TRIPLE-TECT Seal Assembly (500 Series Cast Closed Housing)
Shaft Diameter (S-1) inch - 1.9375
Description - CP2B511-USAF-115TT
Housing Item Number - 039667 DODGE - CH2S-511-USAF
Bearing Item Number - 422123 DODGE - BRG22211KC3
Dynamic Capacity (C) lbf - 31500
Maximum RPM (Grease) - 4500
SNW Item Number - 046352 DODGE - H311-SNW-115
TRIPLE-TECT Seal Item Number - 043540 DODGE - 12TT115
Drop in TRIPLE-TECT Seal Item Number - 039852 DODGE - 12TTDN115
LER Seal Item Number * - 042512 DODGE - 12LER115
Auxiliary (Taconite) Seal Item Number - 041687 DODGE - 12AUX115

Notes :
CP2B - 2 Bolt Base Pillow Block, Cast Iron, One End Closed
5XX - For Adapter Mounted 22200K Series Bearing
USAF - UNIFIED SAF Pillow Block (Inch Dimensions)
115 - 1 15/16”
TT - TRIPLE-TECT
CH2S - 2 Bolt Base Pillow Block, Cast Iron, One End Closed
5XX - For Adapter Mounted 23000K Series Bearing
BRG - Roller Bearing
222 - 22200 Series
K - Tapered Adapter Sleeve Mounting. Otherwise Bearing Has Cylindrical Bore for Direct Mounting.
C3 - Bearing clearance

* LER seals are made from Aluminum

** Images are for representation purposes only
