039126 DODGE - P4B526-USAF-407TTAH

Brand - DODGE
Item Number - 039126 DODGE - P4B526-USAF-407TTAH
Category - USAF 500 Air Handling Pillow Blocks with TRIPLE-TECT Seals
Shaft Diameter (S-1) inch - 4.4375
Description - P4B526-USAF-407TTAH
Housing W/ Stab Ring Item Number - 044031 DODGE - H4S-526-USAF
Bearing Item Number - 422991 DODGE - BRG22226KC3AH
Dynamic Capacity (C) lbf - 170000
Maximum RPM (Grease) - 1800
SNW Item Number - 046431 DODGE - H3126-SNW-407
TRIPLE-TECT Seal Item Number - 043554 DODGE - 54TT407
End Cover Item Number - 040711 DODGE - EC54

Notes :
P4B - 4 Bolt Base Pillow Block, Cast Iron, Both Ends Open
5XX - For Adapter Mounted 22200K Series Bearing
USAF - UNIFIED SAF Pillow Block (Inch Dimensions)
407 - 4-7/16”
TT - TRIPLE-TECT
AH - Air Handling
H4S - 4 Bolt Base Pillow Block, Cast Iron, Both Ends Open
5XX - For Adapter Mounted 22200K Series Bearing
BRG - Roller Bearing
222 - 22200 Series
K - Tapered Adapter Sleeve Mounting. Otherwise Bearing Has Cylindrical Bore for Direct Mounting
C3 - Bearing clearance

** Images are for representation purposes only
