Description
Brand - FAG
Item Number - NU2238E.M1 FAG
Category - Cylindrical Roller Bearing Single Row
Inner (d) MM - 190
Outer (D) MM - 340
Width (B) MM - 92
Inner (d) Inch - 7.4803
Outer (D) Inch - 13.3858
Width (B) Inch - 3.622
Weight (kg) - 37.1
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - M - Brass Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
