Description
Brand - DODGE
Item Number - 127699 DODGE - P2B-SCUEZ-30M-SHCR
Category - E-Z KLEEN Mounted Bearings With Corrosion Resistant Insert (SCEZ Normal Duty Stainless Steel Housed Pillow Blocks)
Series - 206 (SCU)
Shaft Size (mm) - 30
Description - P2B-SCUEZ-30M-SHCR
Description (Standard Insert with Flingers) - P2B-SCUEZ-30M-SH
Weight (kg) - 1.11
Length Through Bore (A) mm - 38.6
Overall Length (B) mm - 158.8
Width (C) mm - 31.8
Bolt to Bolt Minimum Distance (D min) mm - 108.2
Bolt to Bolt Maximum Distance (D max) mm - 127
F-Bolt Diameter - M12
G (mm) - 23.6
H (mm) - 15
Overall Height (J) mm - 81
L (mm) - 39.9
Base to Center Height (M) mm - 42.9
R (mm) - 14.7
S (mm) - 23.9
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
P2B - Pillow block, 2 bolt base
SC - Wide inner ring, normal duty, 65° setscrew locking
UEZ - higher back pillow block, E-Z KLEEN/ULTRA KLEEN (for interchangeability with competitive pillow blocks)
M - Metric
SH - Stainless Steel Housing
CR - Corrosion resistant insert
** Images are for representation purposes only
